PHYSICAL DATA
Temperature Limits: 0°F to 140°F (17.7° to 60°C). Note: Setpoint drift may
occur with ambient temperature changes.
Rated Pressure: 45" w.c.
Maximum Surge Pressure: 10 psi.
Pressure Connections: 1/8" NPT(F).
Electrical Rating: 10A, 120/240 VAC, 28 VDC Resistive 50mA, 125 VDC.
Supply Voltage: 120/240 VAC.
Wiring Connections: Internal Terminal Block.
Conduit Connections: ½" NPT(F).
Set Point Adjustment: Screw type on top of housing. Field adjustable.
Housing: Anodized cast aluminum.
Diaphragm: Buna-N.
Calibration Spring: Stainless Steel.
Installation:Mount with diaphragm in vertical position.
Weight: 3¼ lbs.
Response Time: Switch response time may be as much as 10-25 seconds where
applied pressures are near set point.
|
