PHYSICAL DATA
Maximum Temperature: 220°F (104.4°C)
Maximum Pressure: 1500 psig (103 bar)
Pressure Connection: 1/8" NPT(F)
Electrical Ratings: SPDT or optional DPDT contacts rated 5 A @ 125/250 VAC, 5 A
@ 30 VDC. MV (gold contacts) option for dry circuits rated 1 A @ 125 VAC, 1 A
resistive or 0.5 A inductive @ 30 VDC.
Wiring Connections: 18 AWG x 18" (457 mm) leads. Internal terminal blocks
optional.
Conduit Connection: ¾" NPT
Set Point Adjustment: Screw type, field adjustable over entire operating range.
Housing: Aluminum
Body: Aluminum, Brass, or 316 stainless steel
Diaphragm: Nitrile or Viton®
Weight: 4 lbs., 2 oz. (1.87 kg)
|
