| Service: Water.
Wetted Materials: LFMA, LFMB, LFMC: Body: Polycarbonate; Flange Nut, Float Stop, Male Thread, Metric Union: ABS; Float: 316 SS; O'ring: Fluroelastomer; 90° Elbow: PVC. LFMD, LFME: Body: Polycarbonate; Flange Nut: ABS; Float Stop: Polypropylene; Float: 316 SS; O'ring: Fluroelastomer; Female/Male Thread: PA66 (nylon); 90° Elbow, Metric Union: PVC. LFMF: Body: Polycarbonate; Flange Nut, Metric Union: ABS; Float Stop: Polypropylene; Float: 316 SS; O'ring: Fluroelastomer; Female/Male Thread: PA66 (nylon).
Pressure Limit: 120 psi (8.2 bar) at 68°F (20°C); 90° elbow fittings: 116 psi (8 bar) at 68°F (20°C).
Accuracy: ±5%.
Process Connection: LFMA: 1/2" male NPT (optional 20 mm metric union); LFMB: 1/2" male NPT (optional 20 mm metric union or 1/2" male NPT with 90° elbow); LFMC: 1/2" male NPT (optional 20 mm metric union, 3/4" male NPT, or 1/2" male NPT with 90° elbow); LFMD: 3/4" male NPT (optional 32 mm metric union, 3/4" female NPT, or 3/4" male NPT with 90° elbow); LFME: 1" male NPT (optional 40 mm metric union, 1" female NPT, or 1" male NPT with 90° elbow); LFMF: 2" male NPT (optional 63 mm metric union or 2" female NPT).
Weight: LFMA: 2 oz (56.7 g); LFMB: 3 oz (85.0 g); LFMC: 4 oz (113.4 g); LFMD: 10 oz (283.5 g); LFME: 15 oz (425.2 g); LFMF: 40 oz (1.1 kg).
CAUTION: Series LFM Flowmeters are for indoor use only or areas without direct sunlight. Polycarbonate is adversely affected by ultraviolet light. |
 |
 |
 |
 |
|
|
