  제품명 : Multi-Cal Pressure Calibrator
  모델명 : MC Series
  제조업체 : Dwyer(미국)
  가격 : 견적가
  결재방법 :
  최소주문량 : 1
  납기 : 협의
  운송방법 : 협의
  반품여부 : 가능
  담당부서 / 담당자 : 영업부 / 김병석
  연락처 : 02-0267-0637(011-337-8497)





Series MC Portable Multi-Cal Pressure Calibrator performs a wide variety of simple and complex pressure based measurement, test, and calibration operations. Modular sensor design allows user to select pressure measurement range for application flexibility. Calibrator can accommodate up to two interchangeable pressure modules (sold separately below) in any combination of range or accuracy. Simultaneously display two separate measurements on the two line, alphanumeric display. Readings can be displayed in a choice of seven preprogrammed engineering units or any single user-defined unit. Calibrator features min/max recall, hi/lo alarm, percentage of full scale pressure readings, mA/voltage measurement, leak rate and pressure decay measurement, switch testing capabilities, including trip point and dead band, and velocity/volume flow rates. Quickly document calibration procedures using the data logging feature which stores up to 384 sets of pressure and time/date stamped measurements. Easily upload stored data to an IBM compatible computer via the RS232 port. Calibrators and modules include certification to NIST traceability - ideal as a secondary standard for calibrating pressure equipment. Multi-Cal Pressure Calibrator includes utility software, test leads, protection module, adjustable had strap, AC adapter, two 9V batteries, instruction manual, and hard carrying case. Multi-Cal Pressure Modules are interchangeable and available in a wide selection of pressure ranges and accuracies. Handheld calibrator accepts up to two pressure modules. Modules include NIST calibration certification
Service: Clean, dry, nonconductive, noncorrosive gases. Accuracy: Differential Pressure Modules: ±0.06% FS, Gauge Pressure Modules: ±0.05% FS, Voltage Input: ±0.025% FS @ 1/10 VDC, ±0.10% FS @ 0/30 VDC, Current Input: ±0.03% FS @ 1/20 mA, ±0.05% FS @ 0/50 mA. Sensitivity: ±0.002% of span with dampening 1 part in 50,000 (max.). Repeatability: Ranges ≤0/2 psi: ±0.05% of span, Ranges ≥0/5 psid: ±0.02% of span. Output: RS232 serial interface, 9-pin. Alarm Output: SPST form C 110 VDC, 120 VDC (max.), 1 A (mas.), 30 W, 62.5 VA (resistive). Display: Alphanumeric LCD, 0.37" (9.5 mm) height per line, 2 lines, 16 characters/line. Display Update: 100 msec. Ambient Operation Temperature: 32 to 120°F (0 to 49°C). Storage Temperature: -4 to 158°F (-20 to 70°C). Process Connection: 1/8" female NPT. Electrical Connections: Miniature recessed banana jacks. Power Requirements: Internal: two 9 VDC alkaline batteries, External: AC adapter 9 VDC, 500 mA. Battery Life: 30 hours (approximate). Engineering Units: In H2O, psi, in Hg, kPa, mbar, cm H2O, m Hg, and user-defined. Overpressure: Differential Pressure Modules: 50 psi positive direction, 15 psi negative direction, Gauge Pressure Modules: 2x range (0/5 psi to 0/1000 psi). Temperature Compensation: 20 to 120°F (-7 to 49°C). Temperature Error: Maximum of ±0.004% of span per °F over compensated range for zero and span. Temperature Effect Electrical Measurement: ±0.001% of span per °F over compensated range. Dampening: (Measurement averaging) programmable from 0 to 16 consecutive readings. Baud Rate: 300, 1200, 2400, or 9600, selectable. Housing Material: ABS plastic. Weight: Calibrator: 2.2 lb (1.3 kg); Pressure Module: 0.5 lb (0.3 kg). Agency Approvals: CE.
