PHYSICAL DATA
Accuracy: ±0.5% or ±0.25% F.S.
Service: Air and non-conductive, non-corrosive gases
Output: 4 to 20 mA DC, 2-wire
Supply Voltage: 12-36 VDC
Loop Resistance: 0-1045 ohms Vmin.= 12V + [(.22A)(RL)
Current Consumption: 3.6 mA (min.)
Span and Zero: Externally accessible potentiometers, Non-interactive, ±10%
F.S. adjustment
Response Time: 250 msec maximum
Maximum Pressure: 10 psig (0.7kg/cm²)
Compensated Temperature Range: 35 to 135°F (2 to 57°C)
Operating Temperature Range: -20 to 160°F (-29 to 71°C), 10-95% Rh
Storage Temperature Range: -40 to 180°F (-40 to 82°C)
Thermal Effects: ±0.015% F.S./°F (zero and span) Stability: ±0.5% F.S.O./year
Housing: 300 Series stainless steel (NEMA-2).
Process Connections: Barbed, stainless steel for ¼" I.D. tubing
Electrical Connection: Screw Terminals
Weight: 14 oz. (397 g)
|
