PHYSICAL DATA
Service: Air and non-conductive gases.
Accuracy: ±1% of full scale (RSS) (includes non-linearity, hysteresis, and non-
repeatability).
Output: 4 to 20 mA, 2-wire.
Maximum Pressure: 10 psig (0.7 kg/cm²).
Loop Resistance: 0-800 ohms.
Supply Voltage: 12-30 VDC.
Zero and Span Adjust: ±1 mA, non-interactive.
Compensated Temperature Range: 0 to 150°F (-18 to 65°C).
Thermal Effects: 0.033% FS/°F (0.018% FS/°C).
Temperature Limits: Operating: 0 to 150°F (-18 to 65°C), Storage: -40 to 185°
F (-40 to 85°C).
Housing: Fire retardant glass filled polyester.
Electrical Connection: Terminal strip.
Pressure Connection: 3/16" O.D. fitting for ¼" I.D. tubing.
Weight: 3 oz (85 g).
|
