  Á¦Ç°¸í : Current To Pressure Transducer
  ¸ðµ¨¸í : Model 2343
  Á¦Á¶¾÷ü : Dwyer
  °¡°Ý : °ßÀû°¡
  °áÀç¹æ¹ý : Çö±Ý
  ÃÖ¼ÒÁÖ¹®·® : 1
  ³³±â : ÇùÀÇ
  ¿î¼Û¹æ¹ý : ÇùÀÇ
  ¹ÝÇ°¿©ºÎ : °¡´É
  ´ã´çºÎ¼­ / ´ã´çÀÚ : ¿µ¾÷ºÎ / ±èº´¼®
  ¿¬¶ôó : 02-2637-0637(011-337-8497)





PHYSICAL DATA

Output:    3-15 psig (.21 - 1.1 kg/cm2)
Supply Pressure:    20 psig (1.4kg/cm2) minimum, 100 psig (7.0 kg/cm2) maximum
Pressure Connections:    ¨ù" NPTF (supply and output)
Electrical Connections:    ¨ö" NPTF conduit
Output Capacity:    4.0 scfm (1.9 1/s)
Maximum Air Consumption:    0.1 scfm (.05 1/s) @ 100 psig
Failure Mode:    Upon loss of electrical signal, transducer will fall below 2 psig
Weight:    1.7 lbs, (0.77 kg)
ELECTRICAL
Input Signal:    4-20 mA
Input Impedance:    225 Ohms
PERFORMANCE
Accuracy:    ¡¾ 10% of span
Repeatability:    ¡¾ 0.5% of span
Linearity:    ¡¾ 0.75% of span
Hysteresis:    ¡¾ 0.5% of span
Temperature Range:    0¡Æ to 130¡ÆF (-17 to 55¡ÆC)
STOCKED MODEL
Model 2343...........................................
