PHYSICAL DATA

	Accuracy: ±1% FS including linearity between 59 to 77°F (15 to 25°C) and
		10 to 60 psia (0.7 to 4 bar); ±2% FS from 32 to 122°F (0 to 50°C) and 5 to 150
		psia (0.3 to 10 bar)

	Repeatability: ±15% of full scale.

	Operating Temperature: 41 to 122°F (5 to 50°C)

	Maximum Gas Pressure: 500 psig (34.5 bar).

	Response Time: 0.6 to 1.0 second to within ±2% of setpoint over 20% to 100% FS.

	Power Supply: ±15 VDC; 13.5 Watts maximum.

	Output: Linear 0-5 VDC (2000 ohms min. load impedance); 0 to 10 VDC (4000 ohms min load
		impedance).

	Temperature Coefficient: 0.05% FS/°C or better.

	Pressure Coefficient: 0.01% FS/psi (0.07 bar) or better.

	Leak Integrity: 1 x 10-9; sccs of Helium.

	Max. Particulate Size: 100 microns.

	Computer Interface: RS-485

	Process Connections: ¼" compression fitting for flow rates less than or equal to
		50 L/min; 3/8" for flows greater than or equal to 60 L/min.

	Wetted Parts: 316 stainless steel, 416 stainless steel, Vitron® O-rings.
