  Á¦Ç°¸í : Air Flow Switch
  ¸ðµ¨¸í : Model 530
  Á¦Á¶¾÷ü : Dwyer
  °¡°Ý : °ßÀû°¡
  °áÀç¹æ¹ý : Çö±Ý
  ÃÖ¼ÒÁÖ¹®·® : 1
  ³³±â : ÇùÀÇ
  ¿î¼Û¹æ¹ý : ÇùÀÇ
  ¹ÝÇ°¿©ºÎ : °¡´É
  ´ã´çºÎ¼­ / ´ã´çÀÚ : ¿µ¾÷ºÎ / ±èº´¼®
  ¿¬¶ôó : 02-2637-0637(011-337-8497)





PHYSICAL DATA

Adjustable Range:
    400 - 1600 FPM
(300 - 1600 with vane vertical, pointing up)

 Electrical:

¨ö" HP:


    125 VAC - 9.8 amp full load
           58.8 amp locked rotor
250 VAC - 4.9 amp full load
           29.4 amp locked rotor
Pitot Duty Rating:  470 VA at 125, 250 VAC
Resistive:  15 amp at 125, 250, or 480 VAC

Temperature:
    Maximum 180¡ÆF (82¡ÆC)

Wiring Connections:
    3 screw type; common, normally open and normally closed

Conduit Connection:
    ¨ö" NPT female

Housing:
    Aluminum die casting with chemical conversion coating for corrosion protection; steel stamping, zinc plated

Gasket:
    Silicone rubber

Vane:
    Stainless steel

Installation:
    Mount in any position in horizontal duct

Duct Size:
    6 in. or larger

Weight:
    1 lb., 1 oz.
