Photohelic
PHYSICAL DATA
Maximum Pressure: 25 psig (1.72 bar)
Media Compatibility: air and non-combustible, non-corrosive gases
Accuracy: ±2% of full scale
Operating Temperature: 20-120°F (-6.7 to 48.9°C) (dry air)
Finish: Baked dark gray epoxy hammerloid
Weight: 1 lb., 10 oz. (.74 kg)
Pressure Connections: 1/8 - 27 NPT(F) (duplicated side and back)
Power Supply: 24 VDC, regulated
Electrical Connections: 18" (45 cm) cable assembly with 8 conductors, 3000MR; 6 conductors, 3000MRS
|
