PHYSICAL DATA
Ambient Temperature Range: 20 to 120°F (6.7 to 49°C)
Maximum Pressure: 25 PSIG (1.7 bar); Model No's 3020SGT & 3030SGT - 11 psi (75
kPa); all other units 5 psi (35 kPa)
Accuracy: ±2% of full scale at 70°F (21.1°C) (3% on -0)
Pressure Connections: 1/8" NPT(F)
Case Finish: Dark gray
Conduit Opening: ¾"
Standard Accessories: (2) 3/16" tubing to 1/8" NPT brass adapters for rubber or
vinyl tubing, (1) mounting ring, (1) snap ring, (4) 6 - 32 x 2" mounting
screws, instructions
Compatibility: Use only with air or other non-combustible, non-corrosive gases
Weight: 4 lbs., 12 oz. (2.15 kg)
|
